Airway Pressures

High-Fidelity Catheter for Airway and Esophageal Pressure

Mikro-Cath® Pressure Catheters use Millar’s proven high-fidelity pressure sensor technology to record precise measurements within the airway to advance discovery in respiratory physiology. Signals are unaffected by patient position or movement during respiratory cycles of breathing events such as obstructive sleep apnea.

Precise Airway Pressure Monitoring for Sleep Research

The Mikro-Cath Pressure Catheter enables sleep disorder research specialists, pulmonologists and otolaryngologists to measure high-fidelity airway pressures in patients. The high-fidelity airway and esophageal pressure data supports understanding of respiratory physiology during obstructive sleep apnea and other apneic event studies.

With the Mikro-Cath, clinicians can obtain more comprehensive and accurate measurements for:

  • Airway pressure studies/measurements
  • Obstructive sleep apnea studies
  • Sleep disorder studies

Airway pressure measurements support obstructive sleep apnea diagnosis through direct and reliable pressure readings in comparison to fluid-filled pressure measurements.

What is Obstructive Sleep Apnea?

Obstructive Sleep Apnea (OSA) is a chronic condition characterized by recurrent episodes of partial to complete pharyngeal collapse, which induces apnea and hypopnea during sleep. Initially, the consequences of OSA included sleepiness and daytime fatigue. Upon further investigation, more critical outcomes, such as cardiovascular disease, stroke and decreased life expectancy, were linked to OSA.¹,² While this condition is underdiagnosed in adults, studies have shown a 2–7% prevalence in the population, with risk factors including obesity, age, the male sex, family history and ethnicity.³

Even though OSA was characterized in the 1970s,⁴ there is still no reliable model to predict successful treatments for patients.⁵ Current treatment options for OSA include continuous positive airway pressure (CPAP), oral appliances and surgery. Determining the best treatment option for patients is a challenge for both researchers and clinicians due to anatomical factors that predispose the patient to pharyngeal collapse, combined with their neuromuscular response.¹,⁵ While recent studies have shown an improvement in treatment efficacy using anatomical phenotype models based on airway site collapse, more research is necessary to define these biomechanical models.⁶,

In order to study the biomechanics of pharyngeal collapse, precise airway pressure measurements are needed. The Millar Mikro-Cath diagnostic pressure catheter provides true pressure readings and the ability to detect the slightest changes in pressure. The Mikro-Cath is FDA-approved to record measurement within the patient for up to 24 hours, and with a sensor that is only 3.5F (1.17 mm), the Mikro-Cath creates less discomfort or disturbance for the patient while the catheter is introduced and recording the upper respiratory tract.

Mikro-Cath: The Gold Standard in High-Fidelity Pressure Sensing

The Mikro-Cath Pressure Catheter delivers repeatable, exact data for reliable insight into cardiovascular, respiratory and intracompartmental pressure cases. The solid-state catheter is unaffected by motion artifacts or body position, providing data you can count on when making critical clinical decisions. Mikro-Cath also provides expert evaluation for benchtop studies when evaluating efficacy of medical device performance.

A Millar Mikro-Cath pressure catheter which uses a MEMS pressure sensor to provide accurate, real-time pressure measurements in the body.
A Millar Mikro-Cath pressure catheter which uses a MEMS pressure sensor to provide accurate, real-time pressure measurements in the body.

Case Study: Mikro-Cath Sleep Study

Learn how Dr. Richard Schwab, Professor of Medicine at the Hospital of the University of Pennsylvania, used Mikro-Cath in a study to better understand esophageal pressure during an apneic event.

Close-up of a patient wearing a clear respiratory mask, representing the clinical application of advanced medical technology,
Download Icon

Case Study: Enhanced DISE Protocol with Mikro-Cath

See how Dr. Raj C. Dedhia at the University of Pennsylvania Perelman School of Medicine used Mikro-Cath to enhance Drug-Induced Sleep Endoscopy (DISE) accuracy.

Download Icon

Learn More About Airway Pressures

Download the Mikro-Cath Airway Pressure Catheter information sheet to learn more about Millar’s market-leading solution for obtaining the most accurate and comprehensive pressure measurements.

Sources

¹ Young T, Peppard PE, Gottlieb DJ. “Epidemiology of Obstructive Sleep Apnea: A Population Health Perspective.” Am J Respir Crit Care Med 2001; 165:1217-1239.

² Young T, Peppard PE. “Epidemiology of obstructive sleep apnea.” In: McNicholas WT, Phillipson EA, editors. “Breathing disorders in sleep.” London: W. B. Saunders; 2002. p. 31–43.

³ Kripke DF, Ancoli-Isreal S, Klauber MR, Wingard DL, Mason WJ, Mullaney DL. “Prevalence of Sleep-Disordered Breathing in Ages 40–64 Years: A Population-Based Survey.” Sleep 1997;20(1):65-76.

⁴ Guilleminault C, Tilkian A, Dement WC. “The sleep apnea syndromes.” Annu Rev Med 1976;27:465–484.

⁵ Le T, Moghaddam MG, Woodson BT, Garcia GJ. “Airflow limitation in a collapsible model of the human pharynx: physical mechanisms studied with fluid‐structure interaction simulations and experiments.” Physiol Rep. 2019; 7(10): e14099.

⁶ Vanderveken, OM, Maurer TJ, Hohenhorst W, Hamans E, Lin HS, Vroegop AV, et al. “Evaluation of drug-induced sleep endoscopy as a patient selection tool for implanted upper airway stimulation for obstructive sleep apnea.” J. Clin. Sleep Med. 2013;9:433–438.

⁷ Strollo PJ, Soose RJ, Maurer JT, DeVries N, Cornelius J, Froymovich O, et al. “Upper-airway stimulation for obstructive sleep apnea.” N. Engl. J. Med. 2014;370:139–149.

References to Mikro-Cath Airway Pressure Studies

Harkins, Tice R., et al. “The Whimsical Nature of Airway Obstruction during Drug Induced Sleep Endoscopy.” The Laryngoscope, April 2024, https://doi.org/10.1002/lary.31461.

Dedhia, R. C., Seay, E. G., and Schwartz, A. R. (2021). “Beyond VOTE: The new frontier of Drug-Induced Sleep Endoscopy.” ORL, 84(4), 296–301. http://doi.org/10.1159/000518660.

Garcia, G. J. M., Wolf, J. J., Campbell, D. A., Bailey, R. S., Sparapani, R. A., Welzig, C. M., & Woodson, B. T. (2023). “Mandibular advancement reduces pharyngeal collapsibility by enlarging the airway rather than affecting velopharyngeal compliance.” Physiological Reports, 11(3). http://doi.org/10.14814/phy2.15558.

Ron Oliven, Guy Cohen, Yaniv Dotan, Mostafa Somri, Alan R. Schwartz, Arie Oliven, “Alteration in upper airway dilator muscle co-activation during sleep: comparison of patients with 4 OSA and healthy subjects.” American Physiological Society Journal, vol. 2017, 28 pages, 2017. doi:10.1152/japplphysiol.01067.2016.

Chowdhuri, Susmita, et al. “Effect of Age on Long-Term Facilitation and Chemosensitivity During NREM Sleep.” Journal of Applied Physiology, vol. 119, no. 10, 2015, pp. 1088–1096., doi:10.1152/japplphysiol.00030.2015.

Boudewyns, A.n., et al. “Site of Upper Airway Obstruction in Obstructive Apnoea and Influence of Sleep Stage.” European Respiratory Journal, vol. 10, no. 11, January 1997, pp. 2566–2572., doi:10.1183/09031936.97.10112566.

Sands, Scott A, et al. “Quantifying the Arousal Threshold Using Polysomnography in Obstructive Sleep Apnea.” Sleep, September 2017, doi:10.1093/sleep/zsx183.

Sankari, Abdulghani, et al. “Characteristics and Consequences of Non-Apneic Respiratory Events During Sleep.” Sleep, September 2016, doi:10.1093/sleep/zsw024.

El-Chami, Mohamad, et al. “Time of Day Affects the Frequency and Duration of Breathing Events and the Critical Closing Pressure During NREM Sleep in Participants with Sleep Apnea.” Journal of Applied Physiology, vol. 119, no. 6, 2015, pp. 617–626., doi:10.1152/japplphysiol.00346.2015.

Wellman, A., et al. “Test of the Starling Resistor Model in the Human Upper Airway During Sleep.” Journal of Applied Physiology, vol. 117, no. 12, 2014, pp. 1478–1485., doi:10.1152/japplphysiol.00259.2014.
